Gannet LE
Loitering Effects
The Gannet LE is a precision optically guided delivery system, tube launched from ground or air launched from manned or unmanned systems.
AI Optical Terminal Guidance
The flight control computer contains an AI edge processor capable of performing realtime target detection and classification. This enables the Gannet to autonomously call off a strike mission if collateral damage estimates change after the operator grants terminal guidance authority.
GNSS Denied Resilience
High Grade MEMS INS provides minimal drift in GNSS-Denied Environments. Once in the terminal phase (target lock), no GNSS is required.
Swarming Mesh Capability
The Gannet is intended to operate as a single unit or as a swarm to deliver effects synchronously or in accordance with a pre-planned mission profile.
Technical Specifications
| UAS Weight (with payload) | 3.5 kg / 7.7 lbs |
| Warhead Mass | 600 g / 1.3 lbs |
| Flight Endurance | 20 minutes |
|
Dimensions (Width x Length) Flight Ready Stowed |
1088 x 904 mm / 42.83 x 35.59 ” 125 x 904 mm / 4.92 x 42.83 ” |
| Launch/Recovery Method | Air / tube launch |
Further specifications available on request.
Expression of Interest
Please get in touch if you would like to learn more about the Gannet LE.
